RESETTABLE FUSES?
Reset Your Current
Thinking
|
|
- Personal Computers
- Laptop Computers
- Cellular Phones
- Personal Digital Assistants
- Transformers
- Electric Motors
- Amplifiers and P.A. Systems
- Security and Fire Alarms
- Medical Electronics
- Point of Sale Equipment
- Industrial Controls
- Automotive Electronics and Harness Protection
|
Resettable Overcurrent
Protection
|
Polymer Positive
Temperature Co-Efficient (PTC) Devices
|
|
In an over current or fault condition, the
MultiFuse device's unique
conductive polymer increases its resistance, protecting your
circuit's components from dangerous high current. MultiFuse products are resettable, just
remove the fault and power, and they're ready to provide
protection again.
|
MF-R Series Resettable
Overcurrent Protectors
Reset Your Current
Thinking
|
Hold and Trip
Current Limits
|
V max.
Volts
|
I max.
Amps.
|
Initial
Resistance
|
1 Hour (R1)
Post-Trip
Resistance
|
Max. Time
To Trip
at 5 x Ih
|
Tripped
Power
Dissipation
|
Model
|
Farnell
Order
Code
|
5+
Price
£
|
Amperes
at 23C
|
Ohms
at 23C
|
Ohms
at 23C
|
Seconds
at 23C
|
Watts
at 23C
|
|
Hold
|
Trip
|
Min.
|
Max.
|
Max.
|
|
|
|
0.10
|
0.20
|
30*
|
40
|
2.50
|
4.50
|
7.50
|
4.0
|
0.38
|
MF-R010
|
772-252
|
0.62
|
|
0.20
|
0.40
|
30*
|
40
|
1.74
|
2.84
|
4.40
|
2.2
|
0.40
|
MF-R020
|
772-264
|
0.65
|
|
0.25
|
0.40
|
30*
|
40
|
1.19
|
1.95
|
3.00
|
2.5
|
0.45
|
MF-R025
|
772-276
|
0.66
|
|
0.30
|
0.60
|
30*
|
40
|
0.76
|
1.36
|
2.10
|
3.0
|
0.50
|
MF-R030
|
772-288
|
0.66
|
|
0.40
|
0.80
|
30*
|
40
|
0.52
|
0.86
|
1.29
|
3.8
|
0.55
|
MF-R040
|
772-290
|
0.66
|
|
0.50
|
1.00
|
30*
|
40
|
0.41
|
0.77
|
1.17
|
4.0
|
0.75
|
MF-R050
|
772-306
|
0.67
|
|
0.65
|
1.30
|
30*
|
40
|
0.27
|
0.48
|
0.72
|
5.3
|
0.90
|
MF-R065
|
772-318
|
0.70
|
|
0.75
|
1.50
|
30*
|
40
|
0.18
|
0.40
|
0.60
|
6.3
|
0.90
|
MF-R075
|
772-320
|
0.70
|
|
0.90
|
1.80
|
30*
|
40
|
0.14
|
0.31
|
0.47
|
7.2
|
1.00
|
MF-R090
|
772-331
|
0.70
|
|
1.10
|
2.20
|
30
|
40
|
0.10
|
0.18
|
0.27
|
6.6
|
0.70
|
MF-R110
|
772-343
|
0.70
|
|
1.35
|
2.70
|
30
|
40
|
0.065
|
0.115
|
0.17
|
7.3
|
0.80
|
MF-R135
|
772-355
|
0.70
|
|
1.60
|
3.20
|
30
|
40
|
0.055
|
0.105
|
0.15
|
8.0
|
0.90
|
MF-R160
|
772-367
|
1.00
|
|
1.85
|
3.70
|
30
|
40
|
0.04
|
0.07
|
0.11
|
8.7
|
1.00
|
MF-R185
|
772-379
|
1.01
|
|
2.50
|
5.00
|
30
|
40
|
0.025
|
0.048
|
0.07
|
10.3
|
1.20
|
MF-R250
|
772-380
|
1.05
|
|
3.00
|
6.00
|
30
|
40
|
0.02
|
0.05
|
0.08
|
10.8
|
2.00
|
MF-R300
|
772-392
|
1.09
|
|
4.00
|
8.00
|
30
|
40
|
0.01
|
0.03
|
0.05
|
12.7
|
2.50
|
MF-R400
|
772-409
|
1.13
|
|
5.00
|
10.00
|
30
|
40
|
0.01
|
0.03
|
0.05
|
14.5
|
3.00
|
MF-R500
|
772-410
|
1.17
|
|
6.00
|
12.00
|
30
|
40
|
0.005
|
0.02
|
0.04
|
16.0
|
3.50
|
MF-R600
|
772-422
|
1.20
|
|
7.00
|
14.00
|
30
|
40
|
0.005
|
0.02
|
0.03
|
17.5
|
3.80
|
MF-R700
|
772-434
|
1.24
|
|
8.00
|
16.00
|
30
|
40
|
0.005
|
0.02
|
0.03
|
18.8
|
4.00
|
MF-R800
|
772-446
|
1.28
|
|
* Can be used up to 60v - Consult Farnell
Technical
|

|
